High dynamics for fully digital servo axes. Remote maintenance for all operations as in a local maintenance measure in a technically and legally secure form. Self-configuring Integrated Bus (IGB) for communication between maximum 32 servo inverters.
|Type||Size||Nominal output current (4 kHz) [A]||Max. output current (4 kHz) [A]||Nominal output current (8 kHz) [A]||Max. output current (8 kHz) [A]||Dimensions [mm]|
|SDS5007A||0||4||7.2||3||7.5||300 x 70 x 175|
|SDS5008A||0||2.3||4.2||1.7||4.3||300 x 70 x 175|
|SDS5015A||0||4.5||8.1||3.4||8.5||300 x 70 x 175|
|SDS5040A||1||10||18||6||15||300 x 70 x 260|
|SDS5075A||1||16||28.8||10||25||300 x 70 x 260|
|SDS5110A||2||22||39.6||14||35||300 x 105 x 260|
|SDS5150A||2||32||57.6||20||50||300 x 105 x 260|
|SDS5220A||3||44||79.2||30||75||382.5 x 190 x 276|
|SDS5370A||3||70||126||50||125||382.5 x 190 x 276|
|SDS5450A||3||85||153||60||150||382.5 x 190 x 276|
Asynchronous motors, synchronous servo motors
EnDat® 2.1/2.2 digital, incremental, SSI
With terminal module
EnDat® 2.1 sin/cos, resolver: REA 5001
Pulse/direction signals: REA 5001, SEA 5001, XEA 5001
Optional accessory module for field bus connection:
CANopen® DS-301: CAN 5000
EtherCAT®: ECS 5000
PROFIBUS® DP-V1: DP 5000
PROFINET®: PN 5000
STO, SS1 (SIL 3, PL e, category 3)
Optional accessory module for analog and digital inputs and
outputs as well as encoder interfaces:
Isochronic system bus (IGB) for parameterization and multi-axis applications
Integrated brake control
Fast commissioning with POSITool software
Removable data storage Paramodul for commissioning and service
Automatic motor parameterization from the electronic motor rating plate
Integrated line filter
The 5th generation of POSITool project planning and commissioning software has all the functions needed for efficient use of inverters in single and multi-axis applications.
The inverters are UL and cUL (CSA UL) listed and meet the requirements of UL 508C and UL 840 standards.
All units of the 5th STOBER inverter generation conform to the applicable EMC Directives and meet the criteria of Low Voltage and Machine Directive.
Standard features comprise an effective range of measures, among them an integral EMC filter and the high-quality galvanized sheet steel housing. Levels and terms apply as defined by IEC 1131. All inverters are CE-marked.
